MAN D20 Common Rail Engine Workshop Manual
Complete repair and maintenance guide for the MAN D20 Common Rail engine. This Workshop Manual contains detailed diagrams, step-by-step instructions, specifications and diagnostic procedures for efficient maintenance and troubleshooting. Ideal for professionals and owners of MAN trucks equipped with D20 engines.
- MAN D20 Common Rail repair manual
- Service manual MAN D20 engine
- Manual for repair MAN D20
- MAN D20 engine diagram, diagnostics, maintenance
- MAN D20 Workshop Manual download PDF
MAN D2066 LF EDC 7 Common Rai Workshop Manual
D 2066 LF 04. Euro 3 TGA 310 HP / 228 KW WMAH.
D 2066 LF 03. Euro 3 TGA 350 HP / 257 KW WMAH.
D 2066 LF 02. Euro 3 TGA 390 HP / 287 KW WMAH.
D 2066 LF 01. Euro 3 TGA 430 HP / 316 KW WMAH.
| Password for PDF: truckfixdiagn.com | |
| MAN D2066 LF General Information | Download |
| MAN D2066 LF Engine block and crankcase | Download |
| MAN D2066 LF Cylinder liners, piston clearance in cylinder liner | Download |
| MAN D2066 LF Crankshaft, flywheel, conrods, pistons | Download |
| MAN D2066 LF Engine timing gear, valve timing | Download |
| MAN D2066 LF Cylinder head attachment | Download |
| MAN D2066 LF Removing and installing injectors, rocker arm pivots | Download |
| MAN D2066 LF Valve, valve clearances, engine (exhaust) brake | Download |
| MAN D2066 LF Boost pressure, turbocharger, turbocharger | Download |
| MAN D2066 LF V-belt drives, fan mount | Download |
| MAN D2066 LF Electrically controlled fan coupling | Download |
| MAN D2066 LF Common Rail (cr) system, fuel system | Download |
| Password for PDF: truckfixdiagn.com | |
| MAN D2066 LF Low, high-pressure area, pressure pump, rail | Download |
| MAN D2066 LF Injectors, combustion pressure pattern, speed sensors | Download |
| MAN D2066 LF Separ 2000 filter, operating fluids, | Download |
| MAN D2066 LF Lubricating oil system, engine oil circuit | Download |
| MAN D2066 LF Cooling, Water pump | Download |
| MAN D2066 LF TGA flame start system, air compressor | Download |
| MAN D2066 LF Electrical equipment | Download |
MAN D20, D26 Service Manual. Diagnosis
| Password for PDF: truckfixdiagn.com | |
| MAN D20, D26 General Information | Download |
| MAN D20, D26 Short descriptions | Download |
| MAN D20, D26 Component description/operation | Download |
| MAN D20, D26 Software versions | Download |
| MAN D20, D26 Function parameters (FUP) | Download |
| MAN D20, D26 Repair notes/diagnosis | Download |
| MAN D20, D26 Literature/tools, etc. | Download |
| MAN D20, D26 Error message/descriptions | Download |
| MAN D20, D26 Circuit diagrams | Download |
MAN D20 Typical faults, recommendations for prevention:
🔧 1. Coking of the EGR (exhaust gas recirculation) system
Symptoms: power loss, black smoke, sensor errors.
Cause: soot and deposits in the EGR valve and pipeline.
Prevention:
- Use high-quality fuel.
- Regularly clean the EGR system (every 100-150 thousand km).
- Monitor the serviceability of the turbine and intake system.
🔧 2. Wear or seizure of the turbocharger
Symptoms: loss of power, whistling or humming, oil consumption.
Cause: poor lubrication, overheating, contamination.
Prevention:
- Change oil and filters strictly according to the regulations.
- Warm up and cool the engine before/after the trip.
- Monitor the tightness of the intake and pipes.
🔧 3. Increased oil consumption
Symptoms: constant topping up of oil.
Cause: wear of oil scraper rings, valves, turbine.
Prevention:
- Use original or approved oils.
- Monitor compression and crankcase ventilation.
- Monitor the condition of the turbine.
🔧 4. Problems with the Common Rail system
Symptoms: uneven operation, injector errors, difficult starting.
Cause: fuel contamination, wear of injectors and fuel injection pump.
Prevention:
- Change fuel filters every 60–80 thousand km.
- Use fuel with low sulfur content.
- Check injectors and rail pressure during diagnostics.
🔧 5. Cracks in the cylinder head
Symptoms: overheating, pressure in the expansion tank, coolant leak.
Cause: overheating, factory defect, excessive load.
Prevention:
- Monitor the coolant temperature.
- Do not overload the engine, especially in hot weather.
- Change the antifreeze according to the regulations, use high-quality.
🔧 6. Wear of camshafts and rockers
Symptoms: extraneous sounds in the cylinder head, unstable operation.
Cause: poor lubrication, exceeding maintenance intervals.
Prevention:
- Use original oil and filters.
- Check valve clearances and timing belt condition.
🔧 7. Wiring and ECU problems
Symptoms: spontaneous errors, broken connection with units.
Cause: vibrations, moisture, age.
Prevention:
- Check and clean the ECU connectors and sensors.
- Avoid washing the engine under high pressure.
