Renault Trucks Error Codes List (PDF)
A convenient reference book containing a complete list of Error Ccodes used in Renault Trucks. The document provides decoding of codes, description of malfunctions, possible causes and recommendations for elimination. Such material helps to quickly diagnose problems in the operation of the engine, transmission, electrical equipment, pneumatic system and other units. Useful for mechanics, diagnosticians and equipment owners, allowing to save time on repair and maintenance.
- Renault AE / Magnum 1990–2013
- Renault T / T High 2013+
- Renault Kerax 1997–2013
- Renault Midlum 2000–2013
- Renault Maxity 2007–2019
- Renault Premium Route 1996–2013
| Password for PDF: truckfixdiagn.com | |
| Renault Trucks Error Codes 2003 | Download |
| Engine DXi 11 PDF Error Codes. Programming | Download |
| Renault Truck Fault Codes Braking System, Abs | Download |
| Renault Truck Fault Codes Engine Control Units, Eecu Eup | Download |
| Fault Codes Identification Standard 2006 | Download |
| RENAULT Truck ECM ACM DTCs VMAC IV | Download |
| RENAULT V-MAC 3 Fault Codes DTC | Download |
| Renault Engine DC11 (for Kerax and Premium) Diagnostics Fault Codes | Download |
Most common error codes
💡 These codes are often found on DXi 5, DXi 7, DXi 11, DXi 13 and DTI 8, DTI 11, DTI 13 models.
1. Engine and fuel system
Code Meaning / Possible cause
MID 128 PSID 96 FMI 1/2 Low fuel pressure in the rail Malfunction of the injection pump, leak in the injectors, clogged filter
MID 128 PSID 94 FMI 1 High fuel pressure Pressure regulator jammed
MID 128 SID 146 FMI 5 Fuel pressure sensor error Open or short circuit in the wiring, sensor failure
MID 128 SID 1 FMI 7 Injector failure Electrical failure or mechanical damage
2. SCR / AdBlue system
Code Meaning / Possible cause
MID 128 PSID 90 FMI 1 NOx sensor error (in front of the catalytic converter) Open, corrosion of contacts, sensor failure
MID 128 PSID 91 FMI 1 NOx sensor error (after the catalytic converter) Same as above
MID 128 PSID 100 FMI 1 Low AdBlue Level Level sensor, leak
MID 128 PSID 106 FMI 0/1 Low dosing module performance Clogged injector, pump problems
3. Electrics and CAN bus
Code Meaning / Possible cause
MID 144 SID 231 FMI 9 Lost communication with ABS unit Open circuit in wiring, ABS unit malfunction
MID 140 SID 231 FMI 9 Lost communication with instrument cluster CAN bus, connectors
MID 144 SID 1 FMI 2 Wheel speed sensor error Cable damage, sensor, ABS ring
4. Cooling system
Code Meaning / Possible cause
MID 128 SID 97 FMI 3 High coolant temperature Sensor, thermostat, fan faulty or radiator clogged
MID 128 SID 98 FMI 4 Low level Coolant Level Sensor, Leak
